TYPE-C connector has very efficient transmission capacity richer expandability and stronger power supply capacity, it supports USB3.1 high-speed data connection, audio and video data transmission, and Gigabit Ethernet connection, convenient and efficient, expanding unlimited possibilities. With the support of PD protocol, the power supply capacity can reach up to 20V/5A, or 100W, which not only meets the requirements of mobile phone charging, but also meets the charging needs of portable tablets and notebooks, and the charging and transmission speed is fast, which effectively improves the charging power.
Now the laptop interface is less and less, for example, MacBook, and SurfaceGo connect a display have to drag a bunch of adapters, very cumbersome, the host display connecting lines, monitor power lines, host power lines, and other kinds of connecting lines entangled together, the desk surface looks a mess. With the USB-C interface, you can connect the monitor and notebook only through a USB Type-C cable, to achieve the power cord, data cable, and video signal cable three in one, the connection becomes more simple, and flexible, so that the desktop is neat and beautiful.
TYPE-C connector design is slim, the size is only one-third of the USB3.0 port, support for the ‘forward and reverse plug’ function, we can not consider the positive and negative direction of the plug, even in a poorly lit environment, there is no need to be as entangled in the direction of the MicroUSB jack, to solve the problem of ‘USB always plugged in the wrong way’. It solves the problem of ‘USB always plugged in incorrectly’ and improves the connection efficiency.
TYPE-C Connector Use Precautions
1. For the TYPE-C female connector installation environment requirements, generally if in some kitchens and bathrooms bathroom heavy water vapor places, should be to the TYPE-C female plus protection box, otherwise heavy water vapor places, will make the socket inside the socket easy to short-circuit and thus burn the socket.
2. It is recommended that generally no more than one TYPE-C connector is connected in parallel at the same time, because more than one socket works at the same time, and the power of the operating current is relatively large, far more than the DC power socket to withstand the range. Once the socket can not withstand the excessive current, it may directly cause the possibility of burning the TYPE C chassis.
3. In the plug and TYPE-C female insertion and extraction force should not be too hard to operate, but also not too hard to pull it out, otherwise it is easy to lead to make the plug and TYPE-C female contact appear loose and other phenomena.
4. In the actual socket use, TYPE-C female connector's actual current and voltage parameters can not be greater than the rated value of the socket, and because of the consideration of the USB busbar load, prohibit the TYPE C busbar overloading operation, otherwise, it will lead to cause the socket to short-circuit fire and other accidents.
5. Please prevent water droplets and other moisture liquids from intruding into the TYPE C connector's interface, otherwise it will cause some short-circuit accidents and other problems during the use of the socket. In addition, the plug of the TYPE C female connector should be replaced in time, otherwise, it is easy to appear short circuit and spark phenomenon in use, and the serious point may make the socket internal fire phenomenon.
